1. Hair Removal:
a)Adopting mainstream spot size (15*15mm), the required energy
density of hair removal is strictly base on the clinical tests,
after a series of calculations, the autofit laser output power is
confirmed to be 600W, which ensured superior hair removal results
of the machine.
2. Comfort:
a) In order to achieve effective hair removal results, the laser
module output power is up to 600W. Due to laser reflection, the
shotting window is difficult to maintain a relatively low
temperature during the treatment, what if the heat burns the skin?
We designed an independent metal cold head to solve this problem.
The metal cold head is with good thermal conductivity, can bring
icy experience during treatment.
b) Nonuniform laser output can cause strong pain, in order to avoid
this, a series of theory design, software simulation and practical
tests are conducted by our optical engineers to guarantee the
uniformity of the laser output.
Cooling:
3. Reliability:
a) Laser module with high-quality German-made semiconductor
luminous chip, sealed by advanced nitrogenization technology to
avoid the damage of laser device caused by condensation.
b) Togother with professional power supply manufacturer, we
developed superior quality laser power supply to protect the chip
from overvoltage andovercurrent, ensure the longlife of laser
module.
c) Water Isolation internal layout is design to prevent electrical
safety issues caused by water leakage.
4. Characteristics of Handpiece
- Adopt Germany 600W diode array . Big output power, highly efficient
and long life.
- The technology of sapphire crystal and special coating can enhance
light transmission and uniformity, otherwise, light leak will
influence laser and the skin cooling effect.
- The technology of efficient TEC and constant temperature control
can fully cool the treated areas to avoid pricking during treatment
and the danger of thermal damage to the epidermis,achieving the
effect of painfree hair removal.
- Professional physical design and special electroplating process to
ensure the stability andefficiency of the laser as well as cooling
effect, meanwhile to protecting the laser from damages caused by
cooling water pollution, lack of water and other factors.
- Attractive appearance and easy-to-use design, combined with special
sealing process to avoid the risk of dust pollution and moisture
condensation.
5. Specification:
Laser Type | Diode Laser |
Wavelength (Spectrum) | 808nm |
Energy Density (Fluence) | 1-166J/cm2 (Continuously adjustable) |
Spot Size | 15x15mm2 (Diode Laser) +25x25mm cool head |
Pulse Repetition Rate | 10Hz |
Pulse Duration | 10-400ms |
Cooling | Continuous Crystal contact cooling (-10℃~1℃ ) + Air cooling + Closed water circulation cooling |
Stand-by Working | Continuously for 20 hours |
Display | 10″ True Color LCD Touch Screen |
Electrical Requirements | 100-240VAC, 20A max., 50/60Hz |
Net Weight | 65kgs |
Dimensions (WxDxH) | 48*59*65cm |
